SounDigital SD800.4 EVOX2 4 ohm
3 990 SEK
Nu tillgänglig i vår webbutik: SounDigital SD800.4 EVOX2 4 ohm förstärkare!
Få en enastående ljudupplevelse i ditt fordon med den senaste tekniken från SounDigital. Med SD800.4 EVOX2 4 ohm förstärkare kan du maximera ditt ljudsystem till perfektion.
Denna kraftfulla 4-kanalsförstärkare levererar otroliga 800 watt RMS-effekt till dina högtalare, vilket ger dig en ren och krispig ljudkvalitet.
- Betala säkert och enkelt!
- Mejla oss, vi svarar snabbt!
- Ring oss för eventuella frågor 0735005888
Beskrivning
Art.nr: SD800.4-4 EVOX2
Power @ 2Ω: 4 X 200W
Power @ 4Ω: 4 X 132W
Bridge Power @ 4Ω: 2 X 400W
Bridge Power @ 8Ω: 2 X 264W
Frequency Response (-3dB):
5Hz ~22kHz
Low Pass Filter (12dB/octave):
45Hz ~ 850Hz
High Pass Filter (12dB/octave):
45Hz ~ 850Hz
Operating Voltage:
8V ~ 16V
SNR:
91dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.5 ~ 15V
Current Draw (Music):
35A
Current Draw With Resistive Load:
88A
Total Efficiency:
80%
Damping Factor (@100Hz nominal impedance):
200
Power Cable:
10mm² (7 AWG)
Audio Output Cable:
2 x 1.5mm (15AWG)
Recommended Fuse (Music):
40A
Recommended Battery (Minimum):
60Ah
Width:
4.4 in / 11,3 cm
Length:
5.8 in / 14,8 cm
Height:
2 in / 5,1 cm
Power @ 4Ω: 4 X 132W
Bridge Power @ 4Ω: 2 X 400W
Bridge Power @ 8Ω: 2 X 264W
Frequency Response (-3dB):
5Hz ~22kHz
Low Pass Filter (12dB/octave):
45Hz ~ 850Hz
High Pass Filter (12dB/octave):
45Hz ~ 850Hz
Operating Voltage:
8V ~ 16V
SNR:
91dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.5 ~ 15V
Current Draw (Music):
35A
Current Draw With Resistive Load:
88A
Total Efficiency:
80%
Damping Factor (@100Hz nominal impedance):
200
Power Cable:
10mm² (7 AWG)
Audio Output Cable:
2 x 1.5mm (15AWG)
Recommended Fuse (Music):
40A
Recommended Battery (Minimum):
60Ah
Width:
4.4 in / 11,3 cm
Length:
5.8 in / 14,8 cm
Height:
2 in / 5,1 cm
