SounDigital SD3000.1 EVOX2 2 ohm
7 990 SEK
The 3000.1 EVOX2 is a compact, modern amplifier that delivers 3000W RMS of power over 1 channel.<br />
<br />
EVOX2 is the best series that SounDigital has ever made!<br />
<br />
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.<br />
<br />
Features: <br />
<br />
- New better circuit board<br />
- New RCA connectors<br />
- Better cooling than before<br />
- Renewed signal input: improved interference distance<br />
- better audio quality
- Betala säkert och enkelt!
- Mejla oss, vi svarar snabbt!
- Ring oss för eventuella frågor 0735005888
Beskrivning
Art.nr: SD3000.1-2 EVOX2
Power @ 1Ω: N/A
Power @ 2Ω: 1 X 3000W RMS
Power @ 4Ω: 1 X 1980W RMS
Frequency Response (-3dB):
5Hz – 25kHz
Subsonic Filter (12dB/octave):
5Hz ~ 40Hz
Low Pass Filter (12dB/octave):
50Hz ~ 500Hz
Bass Boost:
0dB ~ 12dB @ 50Hz
Operating Voltage:
8V ~ 16V
SNR:
1Ω: 92dB
2Ω: 90dB
Input Sensitivity (RCA):
0.2V ~ 2V
Input Sensitivity (High Level input):
1.4V ~ 14V
Current Draw (Music):
121A
Current Draw (Max):
242A
Total Efficiency:
86%
Damping Factor (@100Hz nominal impedance):
3000
Power Cable:
35mm² / 2AWG
Speaker Cable:
1Ω: 2 x 6mm² / 9 AWG
2Ω: 2 x 4mm² / 11 AWG
Recommended Fuse* (music):
150A
Recommended Battery (minimum):
150Ah
Width:
5.3 in / 13,6 cm
Length:
8.9 in / 22,8 cm
Height:
2.1 in / 5,5 cm
