Art.nr: 1586
| 9“ HD display Infotainer, upgradable with navigation function*1 | |
| Touch sensitive, capacitive 9”/22.9 cm LCD-TFT HD display (1280 x 720 pixels) with glass surface | |
| OSD menu in 15 different EU languages | |
| DAB+ twin-tuner with dynamic station list, DAB<>FM and DAB<>DAB Service Following, MOT slideshow and DLS-text | |
| FM RDS radio with 18 station presets | |
| Google Android AutoTM | |
| Apple CarPlay | |
| Bluetooth 4.1 hands-free module with A2DP music streaming | |
| Control of up to three cameras systems with auto switching, adjustable grid lines | |
| CAM sensor key for direct camera control | |
| SP-REM remote control App for smartphone control of audio source playback functions (iOS/Android) | |
| RGB multicolor key illumination (amber preset) | |
| 2 x IR remote control incl. Maxi-remote | |
| 4 x 50 W amplifier |
| Bluetooth 4.1 hands-free module | |
| Import of 1,000 phone book entries with 3 phone numbers each | |
| Memory-resident phonebook with direct access to sync’d contacts | |
| Fast dial function for contact favorites | |
| Phonebook contact search function via keypad for given and last name | |
| Source mode for wireless music streaming to external Bluetooth loudspeakers and headphones | |
| iD3-Tag display in A2DP mode (artist, title, album) | |
| Internal Bluetooth microphone, additional input for external microphone*2 |
| DAB+ receiver with twin tuner
| |
| FM RDS radio with 18 station presets and DSP noise masking | |
| Multi-zone function | |
| USB(1) 2.0 port on device backside for CarPlay and Android AutoTM | |
| USB(2) 2.0 port on device backside for A/V file*3 playback from USB memory device | |
| 5-CH time alignment by audio DSP (0 - 10 mS delay) | |
| Graphical 10-band equalizer with 7 EQ-presets | |
| Made for iPod/iPhone | |
| High- and low-pass x-over for Front/Rear/Sub with 12 dB/oct. slopes | |
| HDMI input for compatible accessories and mobile devices | |
| 24 Bit D/A converter |
| 4.2 RCA line pre-out (3 V) | |
| 3 x RCA input for camera video signal (CVBS) with switched power supply and microphone-input (Cam1)
| |
| 1 x DIN FM antenna input socket | |
| 1 x SMB DAB antenna input socket with 12 V phantom power supply | |
| 1 x USB(1) 2.0 port with ~1,000 mA charging current for Apple iOS and Android devices | |
| 1 x USB(2) 2.0 port for A/V file playback (~1,000 mA battery recharging current) | |
| 1 x RCA A/V input for 2-CH audio and video signal (CVBS) | |
| 1 x RCA A/V M-Zone output for 2-CH audio and video signal (CVBS) | |
| 1 x input for external Bluetooth microphone | |
| Input for the connection of the programmable SWC interface | |
| 1 x IR-in for external CAN/SWC interface | |
| 1 x HDMI port |
*1The navigation bundles Z-EMAP66-PC3, Z-EMAP66-MH3 and Z-EMAP66-MH7 are not part of the set content of the Z-N966 device.
*2External microphone contained in the set.
*3Supported A/V file formats: MP3, FLAC, AAC (MP4A), M4A, WAV, AVI, MP4, H.264, MKV 1080p, MPEG2/TS, MPG, WMV, Xvid.
